Rotary Washer Machine

Rotary drum washer is applied to wash potatoes, plantains, sweet potatoes and etc. Rotary washer is the washing section machine in starch processing line and it adopts the principle of countercurrent to clean out mud, sand and small stones effectively.

Send email to us

Product Detail

Main technical parameters

Model	Drum diameter (mm)	Drum length (mm)	Capacity (t/h)	Power (Kw)	Dimension (mm)	Weight (Kg)
DQXJ190x450	Φ1905	4520	20-25	18.5	5400x2290x2170	5200
DQXJ190x490	Φ1905	4920	30-35	22	5930x2290x2170	5730
DQXJ190x490	Φ1905	4955	35-50	30	6110x2340x2170	6000

Features

1Combining the latest technology and years' experience into a whole
2Adopting method of countercurrent washing, excellent washing result, mud and sand removing.
3Reasonable feeding structure. The damage rate of raw material is under 1% and this can ensure high starch extraction yield.
4Compact design, big capacity, energy and water saving
5Material unloaded through blade, which is made of high rigid alloy and can be adjusted .
6Stable operation and rational motor equipped.
7The rotating drum is made of high quality shell perforated with numerical control punch for long time.
8Easy to installation and maintenance.

Show Details

The washing machine is designed with counter-current washing, that is, the washing water enters the washing machine from the material outlet.

Cassavas enter into the ring type washing slot , This wash slot is three phase circle type and adopting countercurrent washing type. The water consumption capacity is 36m3. It can remove mud, skin and impurity from cassava sufficiently.

The cleaned sediment skin falls between the drum and the inner wall of the water tank through the mesh, moves forward under the push of the blades, and is discharged through the overflow tank.

Suitable for sweet potato starch, potato starch and other starch production enterprises.
