Convex-teeth Mill Degerminator

This mill is mainly applied to coarse crashing of steeped corn, facilitate the separation of germ adequately and get the highest germ extraction.This is professionequipment in corn starch processing plant.

Send email to us

Product Detail

Main technical parameters

Model	Rotator diameter (mm)	Rotator Speed (r/min)	Dimension (mm)	Motor (Kw)	Weight (kg)	Capacity (t/h)
MT1200	1200	880	2600X1500X1800	55	3000	25-30
MT980	980	922	2060X1276X1400	45	2460	18-22
MT800	800	970	2510X1100X1125	37	1500	6-12
MT600	600	970	1810X740X720	18.5	800	3.5-6

Features

1 Convex-teeth mill is a kind of coarse crushing equipment used for wet starch production.
2 All parts in connection with material is made of stainless steel to prevent material pollution.
3 Long service life and easy to matintain.
4 1 year warranty and lifelong maintenance.
5 It can also be used coarse crashing of soybean because the spacing is adjustable .

Show Details

The front of the convex-teeth degerminator is fixed with a front bearing sleeve, the front bearing sleeve is fixed with a rear bearing sleeve, the rear bearing sleeve is fixed with a rear bearing, the rear end of the main shaft is installed in the rear bearing, the front part is installed in the front bearing, the central fixed spindle pulley is connected with the motor pulley on the motor shaft through a belt, and the moving disc fixed in the front end of the main shaft is seated in the housing.

Moving plate seat is fixed above the moving gear plate and dial plate, located in the cover of the static plate is installed on the static plate seat, static plate seat and installed on the cover of the static gear plate adjustment device connected together.
